    Asona Triton 100™

    Triton 100™ is a made in NZ 100 mm thick high sound absorbing and thermal insulating ceiling panel. Panels are available in a wide range of decorative finishes and are designed to provide R3.0 thermal insulation and exceptional low, mid and high frequency sound absorption.

    Application:
    Hospitality
    Commercial
    Recreation
    Education
    Healthcare
    Form:
    Grid & Tile
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.90-1.05
    Size:
    100 x 600 x 1200mm
    100 x 1200 x 1200mm
    100 x 1200 x 2400mm
    Made in NZ
    Greentag
    Short Lead Time
    Colour / Finish
    Perforation
    Request Info/Spec Request Sample
    Description
    Specifications
    Downloads

    Triton 100™ is ideal for thermal and acoustic upgrade of classrooms, halls & applications that require control of low frequency reverberation such as music rooms, recording studios, audiology testing rooms.

    Effective broad band sound absorption especially at low frequency, NRC 1.05, ISO class A, αW 1.0.
    Made in NZ for short lead times including replacement parts.
    R3.0 thermal insulation, ideal for building upgrades.
    Fire Group 1-S.
    Broad range of plain Sonatex™ acoustic laminate finishes for design flexibility.
    GreenTag certified, class A.
    Durable and dimensionally stable in high humidity.
    Product stewardship Renew and Reuse program available.
    Packaging take back and reuse scheme available (NZ only).
    Contains 80% recycled glass waste, low VOC.
    Light weight for seismic, easy to work and trim.
    Application:
    Hospitality
    Commercial
    Recreation
    Education
    Healthcare
    Form:
    Grid & Tile
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.90-1.05
    Size:
    100 x 600 x 1200mm
    100 x 1200 x 1200mm
    100 x 1200 x 2400mm

    Composition

    Manufactured in NZ from 48 kg/m³ bio-soluble glass wool absorber, 320 gsm Sonatex™ acoustic laminate finish.

    Technical Datasheets

    Triton 100™
    Drawings

    Triton 100™ Direct Fix

    Triton 100™ Floating Island with Exposed Grid

    Triton 100™ Recessed Downlight

    Triton 100™ Acoustic Panel Cover Join Options

    Triton 100™ Flush Ceiling Join Details

    Triton 100™ Penetration Details & Services Cavity

    Triton 100™ Hip Junction Details

    Triton 100™ Raking Ceiling Long Section Details

    Triton 100™ Insulated Roof Lining
