    Asona Triton Sports 40™

    Triton Sports 40™ panel is a high impact resistant glass fibre acoustical ceiling & wall panel with a smooth, high density glass fabric facing. The panel is designed to provide high sound absorption in areas subject to impact, knocks and bumps.

    Application:
    Education
    Commercial
    Recreation
    Form:
    Grid & Tile
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.95
    Acoustic CAC Rating:
    34
    Size:
    40 x 600 x 1200mm
    40 x 600 x 2400mm
    40 x 1200 x 1200mm
    Made in NZ
    Greentag
    Short Lead Time
    Request Info/Spec Request Sample
    Description
    Specifications
    Downloads

    Triton Sports 40™ panel is ideal for use in classrooms, gymnasiums, halls, and corridors to control reverberation and background noise levels.

    Impact resistant construction, resists damage from bumps and knocks, wont chip or crack and has a puncture resistant facing.
    Proprietary wide faced T38 suspension grid system with CL104 brackets secure the system against ball impact.
    High sound absorption, ideal for large volume spaces. NRC 0.95 for control of reverberation.
    Made in 40 mm thickness or as a Duo 50 panel with a 10 mm plasterboard backer.
    Global GreenTag Certified / Level A
    Can be made in a range of sizes, max width 1000 mm, length to 3000 mm.
    Suitable for ceilings and for high-up level walls.
    Application:
    Education
    Commercial
    Recreation
    Form:
    Grid & Tile
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.95
    Acoustic CAC Rating:
    34
    Size:
    40 x 600 x 1200mm
    40 x 600 x 2400mm
    40 x 1200 x 1200mm

    Composition

    Manufactured from a smooth, high density glass fabric facing laminated to a 96 kg/m³ bio-soluble glass fibre absorber. Rondo Donn DXW 38mm suspension grid from galvanised steel. Made in New Zealand.

    Technical Datasheets

    Triton Sports 40™
    Drawings

    Triton Sports 40™ DHS Purlin Strap Fixing

    Triton Sports 40™ Suspended System

    Triton Sports 40™ Panel Ridge Detail

    Triton Sports 40™ Wall Panels

    Triton Sports 40™ DHS Purlin CLW-95 Clip Fixing

    Triton Sports 40™ Direct Fix

    Triton Sports 40™ 2400x600 with CLW95 Hold Down Clips

    Triton Sports 40™ 1200 x 600 with CLW95 Hold Down Clips

    Triton Sports 40™ CLW95 Wire Hold Down Clip
