    Asona Triton Duo 60™

    Triton Duo™ are made 60 mm thick dual layer composite absorber and attenuator ceiling panel with a Sonatex™ facer on a 50 mm absorber combined with a 10 mm high mass 680 kg/m³ attenuator plasterboard backer. Designed for controlling the reverberation and speech privacy between classrooms, meeting rooms, offices and for the attenuation of rain noise under metal roofing or plenum ventilation duct noise.

    Application:
    Education
    Healthcare
    Commercial
    Recreation
    Form:
    Grid & Tile
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.95
    Acoustic CAC Rating:
    44
    Size:
    60 x 600 x 600 mm
    60 x 600 x 1200 mm
    60 x 600 x 1800 mm
    60 x 600 x 2400 mm
    Made in NZ
    Greentag
    Short Lead Time
    Colour / Finish
    Perforation
    Request Info/Spec Request Sample
    Description
    Specifications
    Downloads

    Triton Duo™ will attenuate rain noise under metal roofs, plenum noise from A/C ducts, provides room to room privacy with ceiling over partition heads and will reduce reverberation times in offices, classrooms, corridors, and meeting rooms.

    Durable resilient construction resists damage from moderate impact; chip, crack resistant.
    NRC 0.95 and CAC 44 for attenuation control.
    Ministry of Education DQLS V3.1 2024 compliant solution.
    Broad range of Sonatex and Sonaris perforated acoustic laminate finishes for design freedom.
    Service panels available to order with temporary foil overlay, designed to protect the decorative finish on site during installation, remove prior to hand over.
    High light reflectance
    Durable and dimensionally stable in high humidity.
    Application:
    Education
    Healthcare
    Commercial
    Recreation
    Form:
    Grid & Tile
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.95
    Acoustic CAC Rating:
    44
    Size:
    60 x 600 x 600 mm
    60 x 600 x 1200 mm
    60 x 600 x 1800 mm
    60 x 600 x 2400 mm

    Composition

    Manufactured in New Zealand from a 50 mm bio-soluble resin bonded glass fibre core with a high mass 10 mm 680 kg/m³ plasterboard attenuator backer and mat white Sonatex™ or perforated Sonaris™ glass mat composite facing.

    Technical Datasheets

    Triton Duo 60™
    Drawings

    Triton Duo 60™ Direct Fix Option

    Triton Duo 60™ CLW190 Hold Down Clip

    Triton Duo 60™ Standard Section

    Triton Duo 60™ ISO View
