    td35 2560x1440 zoom icon

    Asona Triton Duo 35™

    Triton Duo™ are made in a 35 mm thick dual layer composite absorber and attenuator ceiling panel with a Sonatex™ facer on a 25 mm absorber combined with a 10 mm high mass 680 kg/m³ attenuator plasterboard backer. Designed for controlling the reverberation and speech privacy between classrooms, meeting rooms, offices and for the attenuation of rain noise under metal roofing or plenum ventilation duct noise.

    Application:
    Education
    Commercial
    Recreation
    Form:
    Grid & Tile
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.75
    Class C Absorbers
    Acoustic CAC Rating:
    44
    Size:
    35 x 600 x 600mm
    35 X 600 x 1200mm
    Made in NZ
    Greentag
    Short Lead Time
    Colour / Finish
    Perforation
    Request Info/Spec Request Sample
    Description
    Specifications
    Downloads

    Triton Duo™ will attenuate rain noise under metal roofs, plenum noise from A/C ducts, provides room to room privacy with ceiling over partition heads and will reduce reverberation times in offices, classrooms, corridors, and meeting rooms.

    Durable resilient construction resists damage from moderate impact; chip, crack resistant.
    NRC 0.75 and CAC 44 for attenuation control.
    GreenTag Certified / Level A
    Thicknesses: 35 mm and sizes: 600 x 600, 600 x 1200mm
    Made in New Zealand
    Available in a range of decorative acoustic finishes from white or black Sonatex™, colours, prints and in perforated Sonatex™ laminates.
    Application:
    Education
    Commercial
    Recreation
    Form:
    Grid & Tile
    Fire Group:
    Group 1-S
    NRC Sound Absorption:
    0.75
    Class C Absorbers
    Acoustic CAC Rating:
    44
    Size:
    35 x 600 x 600mm
    35 X 600 x 1200mm

    Composition

    Manufactured in New Zealand from 25 mm bio-soluble resin bonded glass fibre core with a high mass 10 mm 680 kg/m³ plasterboard attenuator backer and mat white Sonatex™ or perforated Sonaris™ glass mat composite facing.

    Technical Datasheets

    Triton Duo 35™
    Drawings

    Triton Duo 35™ Direct Fix Option

    Triton Duo 35™ CLW190 Hold Down Clip

    Triton Duo 35™ Standard Section

    Triton Duo 35™ ISO View
